Optical power light source NF-902 manufacturer from China Shenzhen Noyafa Electronic Co., Ltd

Price:	89.0~95.0 USD
Payment Terms:	T/T;Paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: NF-902

Production Capacity: 1000pcs

Delivery Date: 1-5 days

Means of Transport: Ocean,Air

Packing: 24 pieces in a carton

Brand Name: NOYAFA

CW,0HZ modulation output at 650nm , and CW,270Hz,1KHz,2KHz modulation output at other wavelengths.

Description:

As a new-developed one with more functions, NF-906 portable optical power meter has been equipped with ∮1.0mm large-area detector,so that the stability and reliability can be enhanced effectively; it is a kind of portable tester used for the installation\debugging and maintenance of fiber network,which has been widely used in various fields, such as cable construction and maintenance\optical fiber transmission\optical fiber communication\fiber optical sensor\CATV, etc.

Product features:

1.Measurement of the power of optical sender (dBm and W)

2.Loss test of optical fiber link

3.Insertion loss test of optical device

4.Installation and maintenance of fiber link

5. New REF user-defined.

6.User self-calibration function.

7.With FC/SC/ST general-purpose interfaces, free from any complicated transform.

8.With extra-long service life, a common 9V laminated battery serve200hrs' continuous operation.

9.Optional auto-off function and backlight switch.

Technical specification:

Model	NF-906A	NF-906C
Wave-length(nm)	800~1700
Probe	In GaAs
Detection limit	∮1.0mm
Power detecting range(dBm)	-70~+10	-50~+26
Uncertainty degree	±5%
Standard wavelength(nm)	850\1300\1310\1490\1550\1625
Display resolution	0.01dBm
Working temp(℃)	-20~+70
Storage temp(℃)	-30~+80
Automatic shutdown time(min)	15
Battery serving time(h)	200
Overall dimension(mm)	185×105×50
Power supply	9V battery, AC adapter
Weight(g)	350
